>O6KL1D Off-grid Inverter

Please fill in the email and download the information immediately

MPS hybrid inverter
MPS hybrid inverter
MPS hybrid inverter
MPS hybrid inverter
MPS hybrid inverter
MPS hybrid inverter
MPS hybrid inverter
MPS hybrid inverter


MPS hybrid inverter


  • Support PV, diesel generator, battery, load at the same time access, also has strong adaptability, support black start; Various working modes can be set flexibly;


  • Supports unattended operation , with an HMI digital display panel, which quickly judge the operating status and health of the equipment. Combined with cloud-based EMS, it can realize remote monitoring and management.


  • SONECPOWER MPS series hybrid inverters adopt an integrated design, integrating PV controllers, energy storage converters, and on/off-grid automatic switching units, greatly improving customer deployment efficiency and reducing installation costs.


  • The PV capacity can be flexibly configured, greatly improving the microgrid system availability, and is suitable for remote areas and islands where power is relatively weak.


  • Our microgrid inverter's strong load adaptability and complete protection function ensure power supply security and stability.
Description Inquiry Now
Model MPS0030 MPS0050   MPS0100 MPS0150 MPS0250 MPS0500
AC(on-grid)
Max. output power (kW) 33 55 110 165 275 550
Rated output power (kW) 30 50 100 150 250 500
Rated voltage (V) 400
Voltage range (V) 320~460
Rated current (A) 43
 72 144 216 361 722
Rated frequency (Hz) 50/60
Frequency range (Hz) 45~55 / 55~65
THDi <3%
Power factor 1leading-1lagging(settable)
Grid type 3W+N+PE

AC(off-grid)
Max. output power (kW) 33 55 110 165 275 550
Rated power (kW) 30 50
 100 150 250 500
Rated voltage (V) 400
Rated current (A) 43 72
 144 216 361 722
THDu ≤1% linear;  or≤5% nonlinear
Rated frequency (Hz) 50/60
Overload capacity 110% long-term, 120% 1min

PV input
Max. PV input voltage (V) 1,000
Max. PV power (kW) 36/72 60/120 120/180/240 120/180/240 300/360 600/660/720
MPPT module quantity 1/2 1/2 2/3/4 2/3/4 5/6 10/11/12
MPPT voltage range (V) 250~850

Battery
Battery voltage range (V)  250~850 320~850 420~850 420~850 420~850 500~850
Max. charging power (kW) 36/72 60/120 120/180/240 120/180/240 300/360 600/660/720

General data
Dimension W*D*H (mm) 800*800*1,900 800*800*1,900 1,200*800*2,050 1,200*800*2,050 (600*720*2,050)*1+1,200*800*2,050 (600*720*2,050)*2+1,600*1,050*2,050
Weight (kg) 620/650 720/750 1,120/1,150/1,180 1,250/1,280/1,310 1,980/2,010 3,265/3,295/3,325
Operation temperature (℃)  -30 ~ 55
Relative humidity 0 ~95% non-condensing
Ingress protection IP20
Noise emission (dB) <70
Operating altitude (m) <5,000 (>3,000 Derating)
Cooling Air Cooling

Display and communication
Display LCD touch-screen
BMS communication RS485, CAN
EMS communication  RS485, TCP/IP
Certificates

EN 62109-1/-2, EN 62477-1, EN 61000-6-2/-6-4, IEC61727, IEC62116, IEC61683

NRS 097-2-1:2017, ASGC, AS/NZS 4417.1, CEI 0-21, CEI 0-16, G99 EN 50549-1, VDE 4105


SONEC POWER Premium Battery Storage Solutions Advanced Energy Storage for Latin America & Middle East Markets
Lifetime Support Promise
Buy Once, Service Forever
• Free lifetime technical consultation
• Global spare parts network (72hr emergency dispatch)
• Remote diagnostics via SONEC POWER App
• 10-year warranty extendable to 15 years
Military-Grade Safety Systems
5-Layer Intelligent Protection: BMS + EMS + Thermal Control
• Real-time monitoring of voltage/temperature/cell balance
• Auto-shutdown protection against:
- Overcharge/Over-discharge - Short Circuits - Temperature extremes (-20°C to 60°C)
• Active cell balancing technology
• 100% safety record with zero fire incidents
Premium Cell Quality
Engineered with Premium Grade A LiFePO4 Cells
• Sourced from Tier-1 suppliers (CATL/BYD equivalents)
• Rigorous 5-stage quality screening process
• Consistent performance across all climate zon
Choose our benefits

Save more installation, commissioning costs

Reduce the use of fossil fuels and be more environmentally friendly

Continuous and stable power supply

PV expansion will be more convenient in the future
