| Model | R12KLNA | R16KLNA |
| PV input data | ||
| Max. PV input power (kW) | 18 | 24 |
| Max. PV input voltage (V) | 500 | |
| Min. PV input voltage (V) | 120 | |
| Start-up voltage (V) | 120 | |
| MPPT voltage range (without battery)(V) | 120~500 | |
| MPPT voltage range@full-load (V) | 150~430 | |
| Rated PV input voltage (V) | 310 | |
| No. of MPPT trackers | 4 | |
| No. of strings per MPPT tracker | 1/1/1/1 |
|
| Max. input current per MPPT (A) | 16/16/16/16 | 20/20/20/120 |
| Max. short-circuit current per MPPT (A) | 22/22/22/22 | 25/25/25/25 |
| Battery input data | ||
| Battery type | Lithium-ion / Lead-acid | |
| Max. charge / discharge power (kW) | 12 | 13 |
| Battery voltage range (V) | 40~58 | |
| Battery voltage range@full-load (V) | 48~58 | |
| Rated battery voltage (V) | 48 | |
| Max. charging / discharging current (A) | 250/260 | 260/280 |
| Rated charge / discharge current (A) | 250/260 | 260/280 |
| Charging controller | 3-Stage with equalization | |
| Charging strategy for Li-Ion battery | Self-adaption to BMS | |
| BMS communication | CAN | |
| AC output data (grid side) | ||
| Rated output power (kW) | 12 | 16 |
| Max. apparent output power (kVA) | 13.2 | 16 |
| Rated grid voltage( (V) | 110-127/208-240V split phase, 240V single phase | |
| Grid voltage range (V) | 240 | |
| Rated grid frequency (Hz) | 60 | |
| Grid frequency range(Hz) | 55 to 65 | |
| Rated output current (A) | 50 | 66.7 |
| Max. AC output current (A) |
55 |
73.3 |
| Power factor | 0.8leading~0.8lagging | |
| Max. grid passthrough current(A) | 200 | |
| THDi | <3% | |
| Grid type | 2L+N+PE | |
| AC output data (load side) | ||
| Rated output power (kW) | 12 | 13 |
| Max. apparent output power (kVA) | 13.2 | 13.2 |
| Rated output voltage (L-N/L1-L2) (V) | 120/124 | |
| Rated output frequency (Hz) |
60 |
|
| Rated output current (A) | 50 | 54 |
| Max. AC output current (A) | 55 | 55 |
| Peak output power | 110%,30s / 120%,10s / 150%,0.02s | |
| Back-up switch time (ms) | <20 | |
| THDu | <2% | |
| Protection | ||
| Supported protection |
Arc fault protection, PV reverse polarity protection, Anti-islanding protection, Ground fault protection Leakage current protection, Insulation resistance detection, Backup output short circuit protection, AC under-voltage protection, AC output over-current protection, AC over-voltage protection, |
|
| Surge protection | DC Type II / AC Type II | |
| Over voltage category | DC Type II / AC Type III | |
| Certifications and standards | ||
| Certificates |
FCC Part 15 Class B; UL1741,UL1741SA&SB all options, UL1699B, CSA -C22.2 NO.107.1-01,RSD(NEC690.5,11,12) |
|
| General data | ||
| Ingress protection | IP65 / NEMA 3R | |
| Operating temperature range (℃) | -25~+60 | |
| Cooling | FAN cooling | |
| Relative humidity | 0-95% | |
| Operating altitude (m) | 0~4,000 (Derating above 2,000 altitude) | |
| Dimensions W*D*H (mm) | 495 x 900 x 260 | |
| Weight (kg) | 55 | |
| Topology (solar / battery) | Transformerless / Transformer | |
| Noise emission (dB) | 48 | |
| Display and communication | ||
| Display | Touch panel | |
| Communication | RS485, 4G (optional), Wi-Fi | |
Save more installation, commissioning costs
Reduce the use of fossil fuels and be more environmentally friendly
Continuous and stable power supply
PV expansion will be more convenient in the future
